FTTH 16 Cores Sc APC Simplex Fiber Optical Splicing Distribution Box Size 235*125*50mm

Model Number : White Distribution box

Type : Optical Fiber Distribution Box

Place of Origin : Zhejiang, China

Brand Name : OEM

Use : Fiber optic manufacture

Warranty Time : 1 year

Network : None

Wiring Devices : ODF

Certification : CE, ISO, RoHS, GS

Material : PC+ABS

Color : distribution box

Dimensions : 235*125*50mm

Temperature : -50 ~ +85

IP : IP66

Lock : Safe Shaped Lock

Transport Package : Carton

MOQ : 100 pieces

Price : $5.00/pieces 100-499 pieces

Contact Now

Fibconet FTTH High quality 16 cores Sc APC Simplex Fiber Optical Splicing Distribution Box
Products Description
The FTTx distribution box is able to accommodate up to a 1*16 splitter. It is used as a termination point for the feeder cable to connect with drop cable in FTTx network system. It integrates fiber splicing, splitting, distribution, storage and cable connection in one solid protection box.
Specification
FTTH 16 Cores Sc APC Simplex Fiber Optical Splicing Distribution Box Size 235*125*50mm






Application
---Widely used in FTTH access network.
---Telecommunication Networks
---CATV Networks
---Data communications Networks
---Local Area Networks
FEATURE
· Water-proof design with IP-66 Protection level. · Integrated with splice cassette and cable management rods. · Manage fibers in a reasonable fiber radius condition. · Easy to maintain and extend the capacity. · Fiber bend radius control more than 40mm. · Suitable for the fusion splice or mechanical splice. · 1*8 Splitter can be installed as an option. · Efficient cable management. · 8 ports cable entrance for drop cable.
FTTH 16 Cores Sc APC Simplex Fiber Optical Splicing Distribution Box Size 235*125*50mm
FTTH 16 Cores Sc APC Simplex Fiber Optical Splicing Distribution Box Size 235*125*50mm


Technical Parameter:
1. Environmental requirement
Working temperature: -40ºC~+85ºC
Relative humidity: ≤85% (+30ºC)
Atmospheric pressure: 70KPa~106Kpa
2.Main technical datasheet Insertion loss: ≤0.15dB UPC return loss: ≥50dB APC return loss: ≥60dB
3.Thunder-proof technical datasheet:The insulation resistance between the grounding device and the metal parts of the box is no
less than 2x104 MΩ/500V (DC); IR≥2x104 MΩ/500V.
4.The voltage resistance between the grounding device, and the box and its metal parts is no less than 3000V (DC)/min, no puncture, no flashover; U≥3000V
Recommended By Seller
Details Images
FTTH 16 Cores Sc APC Simplex Fiber Optical Splicing Distribution Box Size 235*125*50mm
FTTH 16 Cores Sc APC Simplex Fiber Optical Splicing Distribution Box Size 235*125*50mm
1. Are you a manufacturer or trade company?

We are the manufacturer with nearly 20 years' history.

2. What is your fiber brand?

Our fiber brands include: YOFC, Corning, Fiber Home, J-fiber, POFC

3. What is your main product?

Our main product is Fiber Optic Connector, Fiber Optic Adapter, Fiber Optic Attenuator, Fiber Optic Patch Cord, and Fiber Terminal
Box, except that, we have very good prices for part of the fiber tools!

4. How can we place order?

After we agreed on the product parameters, we will make proforma invoice for your confirmation, when we got your advance payment
(deposit) we will arrange the production and delivery. If you have your ship forwarder, we will use your ship forwarder to deliver
goods; if you don't have ship forwarder, we can ship them by our agent shipping company which can offer very competitive freight
costs!

5. What is the quality of your product?

All of our products are of high quality, we promise 100% recall policy if they are unqualified, we can write it into our contract!

6. How do you arrange the shipping?

Solution A: FIBCONET takes care of everything. Clients only need to collect cargo in locally or wait for cargo delivery to their
office. There are two types of shipping methods available, by sea and by air (Express courier - FedEx/ DHL/UPS/TNT/EMS, we can
ship them according to your express account or ship them by our agent company, the delivery time is about four days).
Solution B: Clients assign a Shenzhen logistic company to do the shipping, FIBCONET follows the company's instructions and finishes the shipping.

7. How can you guarantee the delivery time?

1To avoid the delay, we have built a complete and professional procedure system from production to delivery and have rich
experience. We can regulate the penalty clause in the contract for the late delay.

8. What's your best price for your passive fiber optic product?

Based on the quality of our products and the quantity of your estimated. We would quote the great best matching price all the time.

9. What is your quality control for your fiber optic product?

1. Source Guarantee. We have our long-term cooperation with raw material suppliers. All the products are ROHS certificated and
satisfy exporting quality level demand.
2. Quality Test. It runs through the whole process from the raw material to the finished product, such as package, surface,
physical test, and optical test. They are 100% tested.
3. Optical Test. Our products are strictly tested following IEC and ITU standards.
4. We have 30% spot test by Quality Assurance Department after the products are finished.

10. Why choose FIBCONET Fiber Optic to cooperate?

1. We have first-class production line and strict quality management system.
2. We have professional procedure system and big production capacity to guarantee fast delivery and on-time shipment.
3. We can provide the most competitive price to meet your budget.
4. We also design and innovate new products based on our rich experience.
5. We have professional team to provide comprehensive one-stop service for you.

Please always feel free to contact us for any questions, it's our honor to be in service of you
